TRN 40 HG02 DIN68871AD+B IK HAIMER
Item
FF3213
Že od
164,00 €
HG clamping chuck DIN 69871, Form AD/B, SK 40
Design: Precision balanced, made of alloy case-hardened steel, with a core tensile strength of approx. 950 N/mm² and a hardness depth of min. 0.5 mm. Taper to DIN 254. All functional surfaces machined and guaranteed quality thanks to double 100 % control.
Taper tolerance: AT3
Shank tolerance: h6
Hardened: 60 –2 HRC
Application: For high-precision clamping tools with cylindrical shank using special collets. Also for shanks with clamping surfaces. Very well suited for high-speed machining.
Scope of delivery: HG Clamping chuck with clamping screw and pull-out hook, without collet.
Design: Precision balanced, made of alloy case-hardened steel, with a core tensile strength of approx. 950 N/mm² and a hardness depth of min. 0.5 mm. Taper to DIN 254. All functional surfaces machined and guaranteed quality thanks to double 100 % control.
Taper tolerance: AT3
Shank tolerance: h6
Hardened: 60 –2 HRC
Application: For high-precision clamping tools with cylindrical shank using special collets. Also for shanks with clamping surfaces. Very well suited for high-speed machining.
Scope of delivery: HG Clamping chuck with clamping screw and pull-out hook, without collet.
